BYD CPD 7.0 T ride-on electric forklift is suitable for new energy handling equipment with 7-ton heavy load conditions. Relying on mature lithium battery technology and Seiko manufacturing process, the equipment runs smoothly, has flexible control, low noise and energy saving, and has balanced operation efficiency and safety performance. It can adapt to a variety of complex operating environments, providing practical options for heavy material transfer in enterprises.
The vehicle adopts a pure electric drive scheme, with stable power output and fast response to driving and lifting movements, which helps to improve operation efficiency. The traction and climbing performance is suitable for road conditions such as ramps and road surface height differences in the factory area, and the outdoor factory transfer and indoor warehouse operations can operate stably. Equipped with large-capacity power batteries, it supports long-term continuous operation to meet the continuous handling needs of bulk goods.
The vehicle adopts an AC electronic control system with a hydraulic braking structure, which has sensitive braking and stable operation of the hydraulic system. The noise control in the working area is reasonable, the driving environment is comfortable, and it is suitable for long-term operation scenarios. The body structure is stable, and the load-bearing capacity is adapted to the heavy load demand. With pneumatic tires and reasonable ground clearance, the passability is good, which can reduce the impact of road obstacles.
The vehicle has flexible steering and reasonable turning radius design. In the warehouse with dense shelves and the workshop with compact passages, steering, alignment, stacking and other operations can be successfully completed, and it is suitable for mainstream pallets and storage passages. The gantry runs smoothly, the load-bearing performance of the fork is stable, and heavy cargo lifting, loading and unloading and stacking operations can be completed smoothly.
This forklift is suitable for a variety of scenarios: manufacturing plants can be used for cross-workshop transfer of heavy raw materials and large-scale finished workpieces and station deployment; large warehousing centers, logistics parks and freight yards, suitable for whole pallets of heavy goods in and out of storage, stacking, loading and unloading and short-distance turnover; at the same time, it is suitable for metal processing, building materials, feed, cold chain and other industries to meet the handling needs of heavy materials such as steel, building materials, bulk goods, and cold chain goods.
BYD CPD 7.0 T electric forklift combines the characteristics of heavy-duty capacity, efficient operation, energy saving and environmental protection, safety and durability, etc., with economical operation cost and convenient maintenance, helping enterprises improve material handling efficiency and providing practical equipment solutions for multi-industry heavy-duty handling scenarios.
| parameter name | unit | CPD sentire7.0T |
| manufacturer | - | Home |
| Model | - | CPD sentire7.0T |
| drive | - | electric |
| Manipulation form | - | Car-mounted |
| load capacity | kg | 7000 |
| load center | mm | 600 |
| overhang | mm | 675 |
| wheelbase | mm | 2280 |
| Gross weight (including battery) | kg | 12500 |
| Front/rear axle load, load | kg | 16740/2760 |
| Front/rear axle load, no load | kg | 5820/6680 |
| Wheel category | - | inflatable tire |
| Front wheel size | mm | 8.25-15 |
| Rear wheel size | mm | 250-15 |
| Number of front/rear wheels x = drive wheels | - | 4x/2 |
| front track | mm | 1541 |
| rear track | mm | 1450 |
| Forward/Back Angle | degree | 6-10 |
| Lower limit height of gantry | mm | 2770 |
| Free lifting height | mm | 170 |
| lifting height | mm | 3300 |
| Maximum height of gantry (off the ground) | mm | 4770 |
| Ceiling height | mm | 2780 |
| Seat height (off the ground) | mm | 1708 |
| Traction pin height | mm | 570 |
| full length | mm | 4770 |
| Full length (excluding forks) | mm | 3550 |
| total width | mm | 2076 |
| Fork size | mm | 75/150/1220 |
| ISO 2328 compliant fork racks, frames/forms A, B | - | 4A |
| guardrail margin | mm | 1800 |
| The lower limit of the gantry is the height from the ground | mm | 200 |
| The lower limit of the frame is the height from the ground | mm | 200 |
| Channel width with 1000x1200 horizontal tray | mm | 5355 |
| Channel width with 800x1200 vertical tray | mm | 5555 |
| lower turning radius | mm | 3260 |
| Inward turning radius | mm | 1250 |
| Driving speed, load/no load | Km/h | 16/17 |
| Lifting speed, load/no load | mm/s | 350/400 |
| Drop speed, load/no load | mm/s | 500/400 |
| Upper limit traction S2 = 5min load/no load | KN | 32/28 |
| Upper limit climbing ability S2 = 5min load/no load | % | 15/20 |
| Acceleration time, load/no load (0-10m) | s | - |
| Brake form | - | hydraulic |
| Drive motor power S2 = 60min | kW | 182 |
| Lifting motor power S3 = 15% ED | kW | 242 |
| Battery capacity | V/Ah | 80/840 |
| Battery weight | kg | 1200 |
| Electronic control type | - | AC |
| Hydraulic system working pressure | Mpa | Not more than 18. |
| Noise from the driver | dB (A) | Not more than 80. |
