BYD EL40M Pro 2025 is a 4-ton counterbalanced electric forklift, equipped with BYD's self-developed lithium iron phosphate battery and AC electronic control system, taking into account strong power, energy consumption economy, safety and comfort, suitable for warehousing, manufacturing, cold chain and other heavy material handling scenarios.

Overview of core parameters

• Model: EL40M Pro 2025


• Power form: all-electric (Electric)


• Rated lifting capacity: 4000 kg (load center distance 500 mm)


• Control method: ride type (Seat)


• Drive/lift motor: 21.5 kW/24 kW (AC)


• Battery specification: 80 V/280 Ah lithium iron phosphate battery


• Vehicle weight (including battery): 5360 kg


Second, the core advantages of the product

1. Powerful, heavy-duty and efficient

The full-load/no-load driving speed is 16/18 km/h, and the lifting speed is 380/450 mm/s, meeting the rhythm of high-intensity operation.

Rated traction 15700 N, full load climbing ability of 15%, can adapt to common ramp and heavy load conditions.

Standard solid tire, wear-resistant and impact-resistant, suitable for a variety of floors, reducing the cost of use.

2. Lithium battery drive, economical and environmentally friendly

Using BYD lithium iron phosphate battery, the operation process has no exhaust gas generation, low operating noise, and meets the requirements of green storage.

Battery 80 V/280 Ah, support fast charging, can meet the needs of multi-shift continuous operation.

Fully alternating current (AC) electronic control system offers high energy utilization and lower energy consumption than traditional internal combustion forklifts.

3. Flexible control, stable and safe

The turning radius is 2530 mm, and the width of the 1000-1200 mm horizontal tray channel is 4205 mm, which is suitable for narrow channels and dense shelves.

High-strength gantry, standard lifting height of 3000 mm, lifting height up to 4250 mm, good field of vision, stable stacking operation.

Hydraulic braking system, driver noise ≤ 80 dB (A), equipped with multiple safety protection design, improve work safety.

4. Durable structure and easy maintenance

High-strength box frame, impact resistance, not easy to deform, suitable for long-term continuous operation.

Motor, electronic control and other core components have high reliability and low maintenance; the battery is fully enclosed and does not require daily water maintenance.

With a wide operating temperature range, it can operate stably in a variety of environments, from low-temperature cold storage to conventional outdoor storage.

III. Applicable scenarios

• Warehousing and logistics: high shelf stacking, narrow aisle handling, pallet handling


• Industrial manufacturing: production line material transfer, heavy parts handling


• Cold chain food: low temperature warehouse, cold storage operations


• Supermarket/e-commerce: large-tonnage cargo turnover, intensive storage in warehouses


IV. Summary

The BYD EL40M Pro 2025 is characterized by heavy-duty capacity, long battery life, flexible handling, and low operating costs. It is a practical choice for 4-ton electric forklifts, enabling enterprises to achieve low-carbon and efficient material handling upgrades.
