BYD EL-Pro25MAX is a 2.5-ton ride-on lithium-ion balance forklift, relying on BYD's self-developed lithium-ion battery and electronic control technology, combined with enhanced frame and gantry structure, taking into account heavy load stability, power efficiency and safety and comfort. It is suitable for warehousing and logistics, light industry manufacturing, food processing, factory heavy-duty transfer and other medium and high-strength material handling and stacking scenarios.

Core specifications

• Rated lifting capacity: 2500 kg (2.5 tons), load center distance 500 mm


• Body size: 3567 mm (excluding forks 2497 mm), total width 1170 mm, wheelbase 1605 mm


• Door frame performance: closed height 2010 mm, standard lifting height 3000 mm, lifting height up to 4040 mm, free lifting height 130 mm


• Ground clearance: 105 mm at the gantry, 110 mm at the frame, good passability


• Channel and turning: suitable for 1000-1200 mm horizontal pallet channel width 3830 mm; 800-1200 mm vertical pallet channel width 4027 mm; turning radius 2186 mm, inward turning radius 509 mm


• Fork configuration: size 40/122/1070 mm, fork rack width 1040 mm, in line with ISO2328 standard


• Vehicle weight: total weight including battery 3872 kg; full load axle load 5490 kg/882 kg, no load axle load 1524 kg/2348 kg


• Tire configuration: solid tire, front wheel 7.00-12/5.0EQ, rear wheel 18-7-8, wear-resistant and stable


Power and operating performance

• Power system: equipped with 80 V/210 Ah lithium iron phosphate battery, the battery weighs 154 kg and the size is 722/500/502 mm; matched with AC AC electronic control, the operation is efficient and stable.


• Motor configuration: drive motor 12.5 kW, lifting motor 19 kW, abundant power output.


• Driving speed: full load/no load is 18 km/h, efficient commuting.


• Lifting speed: full load lifting 420 mm/s, no load 450 mm/s; full load/no load descent is 500 mm/s, smooth and smooth operation.


• Traction and climbing: full load rated traction 13137 N, no load 8052 N; full load climbing capacity 18%, no load 20%, can cope with ramp and platform conditions.


• Energy consumption performance: lithium battery drive, no exhaust gas generation during operation, low noise, lower energy consumption cost than internal combustion forklift, suitable for multi-shift continuous operation.


III. Safety and structural configuration

• Braking system: Hydraulic braking, stable and reliable braking, suitable for high-frequency start and stop.


• Hydraulic system: working pressure 140 - 150 bar, stable system operation, lifting and steering responsive.


• Safety protection: Equipped with a high-strength roof guard (height 2193 mm) to reduce the blind spot of the operation; the noise at the driver ≤ 75 dB (A) to optimize the working environment.


• Frame gantry: high-strength design, after intensive testing, stable bearing, suitable for complex working conditions.


IV. Operation experience and application scenarios

• Comfortable design: the height of the seat is 1163 mm, the operation layout is reasonable, and it is not easy to fatigue after long-term operation.


• Easy to control: light steering, clear gear, low difficulty to get started, suitable for high-frequency operations.


• Applicable scenarios: It is suitable for indoor and outdoor conventional environments such as e-commerce warehousing, logistics transshipment, light industry manufacturing, food cold chain, and supermarket warehouses, meeting the needs of 2.5-ton cargo handling, stacking, and loading and unloading.
