BYD EA series 2.0T electric counterweight forklift truck is designed with intelligence, safety, reliability, high efficiency and energy saving as the core direction, providing stable and reliable material handling solutions for warehousing, manufacturing, logistics and other scenarios.
First, power and energy performance
Equipped with BYD blade battery, the battery has high density, high safety characteristics, and good cycle life, providing continuous and stable power output for the forklift.
The battery comes standard with a PTC heating system, which can be adapted to the needs of low-temperature environment operations; the battery protection level can reach IP65, which can adapt to complex working conditions such as dust and splashing water.
The application of permanent magnet synchronization system can increase work efficiency by 10% to 15%, effectively reducing energy consumption while maintaining work efficiency.
II. Safety and stability
The lost-load height can reach 3.7 meters, the vehicle stability safety factor can reach 2.2, and it runs smoothly under high-level operation conditions, meeting the material handling requirements of most medium and high stations.
Equipped with core components such as reinforced frame, drive axle housing, and special tires, the key parts of the body are made of high-strength steel or thickened and enlarged treatment, providing stronger impact resistance and wear resistance, and stable durability.
III. Operation and maintenance experience
Equipped with a 7-inch color LED display, the operation information is clear and easy to read; with semi-enclosed seats, it optimizes the driving experience and relieves long-term work fatigue.
Adopt tool-free removal of hydraulic tank cover and open dashboard design, which is convenient for daily inspection and maintenance, reduces downtime, and improves operational efficiency.
BYD EA series 2.0T electric counterweight forklift, with reliable power, stable safety design, efficient performance and convenient use experience, provides efficient, low-cost and worry-free operation support for enterprise material handling, making it a practical choice for handling equipment in multiple scenarios.
| parameter item | unit | EA20 |
| Model | / | EA20 |
| dynamic form | / | electric |
| mode of operation | / | car |
| Rated lifting capacity (Q) | t | 2000 |
| Load center distance (c) | mm | 500 |
| Front overhang (x) | mm | 460 |
| Wheelbase (y) | mm | 1700 |
| Gross weight (including battery) | kg | 3200 |
| Axle load (full load) | kg | 4570/630 |
| Axle load (no load) | kg | 1470/1730 |
| Tire form | / | inflatable tire |
| Front wheel size | mm | 7.00/12-12PR |
| Rear wheel size | mm | 6.00-9-10PR |
| Number of front/rear wheels, x = drive wheels | / | 2x/2 |
| Front track (b10) | mm | 975 |
| Rear track (b11) | mm | 970 |
| Forward/Backward Angle (α/β) | 6-12 | |
| Door frame height (h1) | mm | 2050 |
| Free lifting height (h2) | mm | 120 |
| Standard gantry lifting height (h3) | mm | 3000 |
| Maximum height of gantry (off the ground) (h4) | mm | 4040 |
| Top frame height (h6) | mm | 2080 |
| Seat height (off the ground) (h7) | mm | 1100 |
| Traction pin height (h10) | mm | 265 |
| Full length (l1) | mm | 3680 |
| Full length (excluding fork) (l2) | mm | 2610 |
| Overall width (b1/b2) | mm | 1160 |
| Fork size (s/e/l) | mm | 40/100/1070 |
| ISO 2328 compliant fork racks, frames/forms A, B | / | 2A |
| Fork rack width (b3) | mm | 1040 |
| The lower limit of the gantry is the height from the ground (m1). | mm | 115 |
| The lower limit of the frame is the height from the ground (m2). | mm | 140 |
| Channel width with 1000x1200 horizontal tray (Ast) | mm | 4100 |
| Channel width with 800x1200 vertical tray (Ast) | mm | 4300 |
| Lower turning radius (Wa) | mm | 2380 |
| Inward turning radius (b13) | mm | 823 |
| Driving speed, load/no load | km/h | 16/17 |
| Lifting speed, load/no load | mm/s | 400/450 |
| Drop speed, load/no load | mm/s | 400/450 |
| Upper limit traction, S2 = 5min, load/no load | KN | August 13 |
| Upper limit climbing ability, S2 = 5min, load/no load | % | 16/18 |
| Brake form | / | Mechanical/Electrical |
| Drive motor power, S2 = 60min | kw | 12 |
| Lifting motor power, S3 = 15% ED | kw | 15 |
| Battery capacity | V/Ah | 76.8/210 |
| Battery weight | kg | 150 |
| Battery size L/W/H | mm | 700/500/500 |
| VDI cycle type energy consumption | kw/h | / |
| Electronic control type | / | Permanent magnet |
| Hydraulic system working pressure | bar | 160 |
| Noise at the driver | dB (A) | ≤75 |
| Traction connection | / | PIN |
